how it's made
facility
Our facility includes everything necessary to fully fabricate finished casework and other manufactured goods. From hand tools to CNC automated equipment, our production and custom shops are set up to handle the work and maintain quality throughout each production stage. Below is information regarding some of the manufacturing equipment used in our shops.
Stiles HOMAG centatec N-500 V12 with off-feed
THE BACKBONE OF PRODUCTION
The HOMAG CENTATEQ N-500 gantry-style CNC processing center is designed for the highest precision over the total working width. That means the entire working field is reachable with all processing tools, so you can nest parts utilizing the full panel size.
MANUFACTURING CAPABILITIES
The flexible MATRIX table system includes multi-functional clamping systems for superior part hold down. The CENTATEQ N-500 platform is also built for material handling integration including in-feed/out-feed tables,. STORETEQ/robotic material handling systems, and more.
- Assembled, tested, and shipped from our Grand Rapids, Michigan facility
- Integrated C-axis enables aggregate capabilities
- Dual Z-axis maximizes processing speed and tool-changing efficiency
- 5’x10’, 5×12’, 7’x10’, and 7’x14’ table sizes
stiles homag sawteq s-200
QUICK + CONTROLLED CUTTING
The SAWTEQ S-200 offers everything you need in a woodworking shop to cut panels horizontally: power, precision and above all flexibility.
THE PROCESS
It begins with the technology: the SAWTEQ-200 offers you a choice between two standard models and a wide range of technology options, allowing you to customize your machine to meet your specific requirements. You remain flexible and have a saw that can grow with your needs.
stiles homag drillteq d-510
HORIZONTAL PRECISION
As both an individual machine or a complementary product in connection with a CNC processing center, the DRILLTEQ D-510 allows complete and precise processing in the edge area by the clever combination of drilling, doweling, and routing.
Whether you utilize a traditional wooden dowel within your case construction, or a connector or other hardware requiring more advanced drilling and routing capabilities, the DRILLTEQ D-510 can meet your needs.
BENEFITS
- Increased efficiency by faster operating procedure with intelliGuide Classic
- Increased horizontal and vertical drilling functionality
- Capabilities to include both horizontal and vertical routing to the platform
- Accurate drill holes and precise positioning of dowels by high-speed drilling and dowel insertion aggregate
- Vertical drilling in the border area, ideal for connection fittings or hinge drill holes
- Up to 8 adjustable clamping cylinders enable a secure and gentle fixing of the workpieces
- The lowerable center stop allows for flexible handling of workpieces thereby ensuring an optimum two-field operation.
stiles homag edgeteq s-380
THE PERFECT EDGE
The HOMAG EDGETEQ S-380 Series edgebanders take the S-300 series to the next level by offering additional processing abilities and speed. The S-380 offers greater production capacity along with larger processing stations to ensure perfect edges for medium-to-large scale customers. Introduction to our universal premelter allowing quick change overs between glue types. While securing the workpieces with an upper pressure belt compared to rollers.
stiles homag edGETEQ XES 200
LESS DOWNTIME, LESS COST
The HOMAG EDGETEQ XES 200 is a glue unit that allows for the safe and efficient storage of PUR adhesives when it is not in use. The vacuum technology that seals the unit ensures that the PUR remains stable for overnight storage. Additionally, the pre-heating stand allows for quick changeovers by heating the glue unit for production purging and routine maintenance.
